265-001SS20K-4-C40

DN40CF POWER GLOVE HIGH VOLTAGE F/T, 4 x SS CONDUCTOR, 20KV, 1A, AIR SIDE CABLE & HV POWER GLOVE

$ 871.50

Would you like to know when we've got stock?

PRICES INCLUDE IMPORT DUTY, BROKERAGE FEES & TAXES, AND INTERNATIONAL SHIPPING

Vacuum Leak Rate UHV <5x10-10 mbar l/s
Size or DN DN40CF (2 ¾” OD flange)
Body Material 304 Stainless steel
Number of Pins 4
Voltage Rating 20kV
Temperature Range -100°C to 450°C (without connector)
Conductor Material Stainless steel
Max Current 1A

• Pin Diameter - 2.4mm each
• Pin material – Stainless Steel
• Power Glove High Voltage feedthrough includes air side insulation cover & 2.4m of high voltage cable
