262-TCN-4-C40

DN16CF THERMOCOUPLE FEEDTHROUGH, TYPE N, 4 PAIRS, AIR & VACUUM-SIDE CONNECTORS

$ 1,050.00

Would you like to know when we've got stock?

PRICES INCLUDE IMPORT DUTY, BROKERAGE FEES & TAXES, AND INTERNATIONAL SHIPPING

Vacuum Leak Rate UHV <5x10-10 mbar l/s
Size or DN DN40CF (2 ¾” OD flange)
Compliance Type N thermocouple
Conductor Material .
Body Material Stainless Steel/Ceramic
Temperature Range -100°C to 450°C
Number of Pins 8

• Vacuum side pins terminate with a screw connector (included)
• The (+) pole (Nicrosil) is shorter than the (-) pole (Nisil)
• Screw connector included for the air side.
• Type N thermocouple temperature range: -250^oC to 1300^oC
