PRICES INCLUDE IMPORT DUTY, BROKERAGE FEES & TAXES, AND INTERNATIONAL SHIPPING
Specifications
Vacuum Leak Rate UHV <5x10-10 mbar l/s
Size or DN DN40CF (2 ¾” OD flange)
Compliance MHV 50 ohm
Pin Gender Air Female/Vacuum Male
Conductor Material Stainless steel 304
Vacuum Seal Ceramic
Body Material Stainless Steel
Voltage Rating 5 kV DC
Max Current 3A per pin
Magnetic Permeability Not constant
Temperature Range -200°C to 250°C (Air side Connector -65oC to 165oC)
Impedance 50 ohms
Number of Pins 3
1 PDF' and other files associated with this product
If you would like us to arrange a quote for you, please apply your details here.
