Vacuum Leak Rate UHV <5x10-10 mbar l/s
Size or DN DN63CF (4 ½ " OD flange)
Compliance ISO 3669:2017
Vacuum Seal Annealed Cu Gasket
Body Material Stainless Steel 304
Temperature Range -100°C to 200°C max
Transmission 193nm
Inside Diameter 68mm
Flatness λ/4 @632nm
Coating V-coat with <0.25% reflection/surface
Parallelism <10 arc sec
Surface Finish 20/10 Scratch/Dig
Optical Material Excimer grade fused silica
